IC693/IC694MDL754: Must

configure 16 module status

bits

Always configure sixteen bits of module status when using module MDL754. Configuring zero

bits of module status will result in invalid data in the ESCP status bits of the module.

IC695ALG600 Lead Resistance

Compensation setting.

A configuration store operation will fail if a channel is configured for 3-wire RTD and Lead

Resistance Compensation is set to Disabled. A Loss of Module fault will be logged in the I/O

Fault table at the end of the store operation.

To recover the lost module, the configuration must be changed to enable Lead Resistance

Compensation and module must be power cycled.

WinLoader may stop

operating.

On computers running Windows 2000 and using some versions of Symantec Antivirus

protection, WinLoader will lock up if used in advanced mode. Recovery requires cycling the

computer's power.

Logic and HWC Not Equal

after power cycle.

If the Hardware Configuration from Target 1, with Logic/Configuration Power-up Source and

Data Source both set to Always from Flash, is stored in Flash, then Logic and Hardware Config

from Target 2, with Logic/Configuration Power-up Source both set to Always from RAM, are

stored to RAM and there is a good battery, then when power is cycled the programmer may

show that Logic and Hardware Config are Not Equal.

The remedy is to clear Flash and re-store the Logic and Hardware Config from Target 2.

WinLoader does not detect PC

COM port in use when

upgrading PACSystems CPU.

WinLoader does not detect if a PC's COM port is in use when attempting to connect to a

PACSystems CPU to perform a firmware upgrade. If the port is already in use it displays the

status trying to connect followed by waiting for target. To proceed with the upgrade, press the

abort button and disconnect the other application that is using the COM port.

CPU320, CRU320 user

application and values

cleared after power cycle.

Under rare circumstances during multiple rapid power cycles the CPU320/CRU320 will power

up with the user application and data in RAM cleared. There will be a Corrupted user memory

fault in the controller fault table (Group 130, Error code 1). This will not occur if the user

application and data are loaded from flash on power-up (Always Flash or Conditional Flash)
