Restriction/Open Issue Description

Missing Addition of IOC event

when ECM850 module restarts

due to reset pushbutton or

SVC_REQ 24

When ECM850 module RESET is triggered using SVC_REQ 24 or Reset pushbutton, CPU does

not report Addition of IOC fault message in Controller fault table after successful reset of

module.

Rare condition of CPU lights

out during power cycles

In rare instances during multiple rapid power cycles, the CPU will fail to power up. If this

occurs, the CPU should recover with the next power cycle.

The Ethernet module fails to

exchange EGD properly during

power cycling

Very rarely, after experiencing multiple rapid power cycles, the CPU may fail to establish

communication with one or more modules in the backplane at power up. When this occurs,

several pairs of a Loss of, or missing option module and Reset of option module faults will be

logged in the controller fault table.

If the module is an ETM, an event 30H is recorded in its station manager event log.

To recover from this issue, cycle power again.

Loss of power supplies after

firmware update

A Loss of Power Supplies after firmware update may occur. This does not happen with all

firmware updates and will NOT occur if the system is power cycled after the firmware

upgrade has completed. The faults displayed when this issue occurs are as follows:

Loss of, or missing option module

Error Code: 36

Group: 4

Action: 3:Fatal

Task Num: 9

Fault Extra Data: 01 58 02 4f 80 08 0a 07 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

Battery installation. When installing a new battery, if there currently is no battery installed, the battery must be

installed while the CPU has power. Failing to follow this procedure could result in the CPU not

powering up.

If a battery is installed while power is off (and there was no battery previously installed), and

the CPU fails to power up, remove the battery, power cycle the CPU and then install the

battery.

Hot swapping some analog

modules slowly may result in

modules not being recognized.

Occasionally during a hot insertion (hot swap) of RX3i Non-Isolated Analog Input Modules,

input channels may take up to 2 seconds to reflect actual input values after the module OK

bit is enabled in the module status word. This has only been seen when the hot insertion has

been done slowly (i.e. approximately 1.5 seconds to insert the module). Refer to PACSystems

RX3i System Manual, GFK-2314F or later for updated hot-swap information.

Ethernet disconnect during

Word-for-Word change.

If the Ethernet connection is broken during a word-for-word change, the programmer may

not allow a subsequent word-for-word change after reconnecting due to the fact that it

thinks another programmer is currently attached. If this occurs, you should go offline and

then back online again.

Simultaneous Clears, Loads

and Stores not supported.

PACSystems CPUs do not support multiple programmers changing CPU contents at the same

time. The programming software may generate an error during the operation. Simultaneous

loads from a single CPU are allowed.
