199A5930P0101 GE Module cards in stock

The following are required to use the features introduced in the most recent CPU release:

Subject Minimum Version Required

Programmer Version

Requirements

PME 8.50 SIM 2 or later.

Supports the HART Pass

Through Feature

HART-capable RX3i Analog I/O modules can communicate HART data via this CPU to

compatible asset management tools. Refer to the PACSystems HART Pass Through User

Manual, GFK-2929 for more details.

The following RX3i analog modules support HART:

IC695ALG626

IC695ALG6283

IC695ALG728

If used for HART Pass Through, the supporting RX3i PROFINET Controller (PNC001) and

PROFINET Scanner (PNS001 or CEP001) must also contain HART-compatible firmware:

IC695PNC001 Firmware Release 2.20

IC695PNS001 Firmware Release 2.30

IC695CEP001 Firmware Release 2.30.

C Toolkit Compatibility The C Toolkit for PACSystems is distributed with Proficy Machine Edition Logic Developer.

Updates can be downloaded from http://www.ge-ip.com/support.

C Toolkit Release 5.50, distributed with Machine Edition Logic Developer 5.9 or later, is

required for use with the CRU320.

Note: C blocks that were built using C Toolkit versions earlier than 5.00 Build 16C1 must be

recompiled using a newer toolkit version for use with CPU firmware release 5.00 or

higher.

Note: The Series 90 Toolkit (IC641SWP709/719) is not compatible with PACSystems.

RS-485 Port Compatibility When the CPU is first powered on, the RS-485 port (COM 2) powers up with the transmitter

enabled. The transmitter is placed into a high-impedance state once the CPU OK LED is

illuminated. Since that takes a finite amount of time, this could be an issue if the COM 2 port is

being used in multi-drop communications, and other devices share the same cable via wiredOR connections. If one of those devices is actively communicating when the CPU is powered

up, there is a potential for those communications to be disrupted until the CPU puts the

RS-485 port into high-impedance state.

Low Battery Detection For the low battery detection circuit to function properly, a Smart Battery must be used.

For details, refer to the PACSystems RX3i and RX7i Battery and Energy Pack Manual, GFK-2741

Rx3i Backplane Hardware

Revision

For the CRU320 CPU, one of the following backplane hardware revisions MUST be used:

IC695CHS012-BAMP

IC695CHS016-BAMP

IC695CHS012CA-BAMP

IC695CHS016CA-BAMP

or

IC695CHS012-CA (or later)

IC695CHS016-CA (or later)

IC695CHS012CA-CA (or later)

IC695CHS016CA-CA (or later)

Motion Module not supported

by Redundancy CPU

The CRU320 does not support the PMM335 PACMotion Multi-Axis Motion Controller.

Backplanes, power supplies

and I/O modules

For lists of compatible backplanes, power supplies and I/O modules, refer to the PACSystems

RX3i System Manual, GFK-2314F or later.

Series 90-30 Expansion Rack

Compatibility

Series 90-30 expansion racks, both local and remote, are supported by the PACSystems RX3i

System. PACSystems RX3i CPUs must be located in an RXi Universal Backplane. They do not

operate in a Series 90-30 Rack.

Series 90-30 Main Rack

Compatibility

Series 90-30 Main Racks cannot be used in a PACSystems RX3i system.

Series 90-30 CPUs do not operate in PACSystems RX3i Racks.
