193X476ABG01   GE  Module cards in stock

193X476ABG01 GE Module cards in stock

Brand: GE                 Model number:193X476ABG01

Colour:new                  Warranty: 193X369ABG01

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.12kg

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

193X476ABG01   GE  Module cards in stock

193X381AAG01   GE  Module cards in stock

The block’s advanced diagnostics provide the messages listed below.

Fault messages can be cleared from the Hand-held Monitor or the CPU.

High Alarm: Input over its high alarm limit

Low Alarm: Input under its low alarm limit

Open Wire: Input configured for 4-20mA is below 2mA

Overrange: Signal exceeds +32767 engineering units or +4095 counts

Underrange: Signal exceeds -32767 engineering units or -4095 counts

Configuration ___________________________________

First, the block must be configured with a Hand-held Monitor to:



Enter its Device Number (serial bus address).



Enter its Reference Number (required only for IC600 and IC550

series PLCs only).

Note: If a block is configured offline, it must be properly grounded and

have a 75 Ohm resistor installed across its Serial 1 and Serial 2

terminals. See the Discrete and Analog I/O Blocks User’s Manual for

instructions. The rest of the features can be configured either using a

Hand-held Monitor, or by sending a Write Configuration datagram to the

block from the host.

Feature Circuit

or Block

Factory

Setting

Selections

Device Number Block null 0 to 31 (a number must

be selected)

Reference

Address

Block none Depends on host CPU

type

Baud Rate Block 153.6 std 153.6 std, 153.6 ext,

76.8, 38.4 Kbd

Report Faults Circuit yes yes/no

Range Select* Circuit +/-10VDC 0-10VDC, +/-10VDC, 0-

5VDC, 5VDC, 4-20mA (1-

5VDC)

Scaling Points Circuit +/-10000,

+/-4095

+/-32767, +/-4095

Input Filter Time* Circuit 128ms none, 8-1024ms

Alarm Input Mode Circuit no yes/no

Alarm Thresholds Circuit +/-10000 +/-32767

Hold Last State Circuit no yes/no

Output Default Circuit 0 +/-32767 eng. units

BSM Present Block no yes/no

Outputs Default

Time

Block 3 bus scans 2.5/10 seconds

CPU Redundancy Block none none/standby

Configuration

Protection

Block disabled enabled, disabled

* These are setup parameters. They must NOT be changed while the

block is operating. If either is changed while the block is operating, the

voltage of the circuit also changes
