Brand： GE Model number：193X381AAG01
Colour：new Warranty: 193X369ABG01
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.12kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
193X381AAG01 GE Module cards in stock
The first four circuits on the block are inputs. They convert incoming
signal voltage or current to a digital count value in the range +/-4095.
If scaling has been configured for an input, the block automatically
scales the digital count value to an engineering units value.
Processor
Case
Ground
Shield
Filter
IN
COM
GND
JMP
A/D AMP
Analog to Digital
Converter
MUX
RTN
Power
Supply
Ground
NOTE:
Common ground and case
ground are shared between
two output channels
Circuits 5 and 6 are outputs. The block will automatically scale an
engineering units output from the CPU to a digital count value in the
range +/-4095. The D/A converter then converts the digital value to
an output signal voltage or current.
+20V
-1 Processor
V to I
Converter
COM
GND Case
Ground
+1
S/H
VOUT
D/A
Power
Supply
Ground
Buffer
Amplifier
Sample
Hold
Circuitry
12 bits plus
sign D/A
Converter
Common ground and case
ground terminals are shared
between output channels
NOTE:
Circuit Scaling
Each circuit can be configured for scaling to represent a different
type or increment of engineering units. The default for each circuit is
to operate in the range of +/-10VDC, and to report engineering units
of millivolts. If millivolts are not appropriate or if the circuit will
operate in a different voltage/current range, the circuit should be
rescaled. Instructions are given in the Discrete and Analog Blocks
User’s Manual. The possible range of engineering units values is
+/-32767. A circuit can also be configured for no scaling; in that
case, it uses unscaled digital count values that correspond directly
to the actual analog signal level. The range of digital counts values
is +/-4095.
LEDs _________________________________________
The block's Unit OK and I/O Enabled LEDs show its operating
status:
Unit OK I/O
Enabled
Meaning
ON ON Block functioning, CPU communicating
ON OFF Block functioning
No CPU communications for 3 bus scans
ON Blinking Block functioning, Circuit forced
Blinking ON Circuit fault, CPU communicating
Blinking OFF Circuit fault
No CPU communications for 3 bus scans
Alternate Blinking Circuit fault, Circuit forced
Synchronous
Blinking
No CPU communications - block number
conflict
OFF OFF No block power, or block faulty
