193X375AAG01   GE  Module cards in stock

193X375AAG01 GE Module cards in stock

Brand: GE                 Model number:193X375AAG01

Colour:new                  Warranty: 193X369ABG01

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.12kg

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

193X375AAG01   GE  Module cards in stock

193X375AAG01   GE  Module cards in stock

The first four circuits on the block are inputs. They convert incoming

signal voltage or current to a digital count value in the range +/-4095.

If scaling has been configured for an input, the block automatically

scales the digital count value to an engineering units value.

Processor

Case

Ground

Shield

Filter

IN

COM

GND

JMP

A/D AMP

Analog to Digital

Converter

MUX

RTN

Power

Supply

Ground

NOTE:

Common ground and case

ground are shared between

two output channels

Circuits 5 and 6 are outputs. The block will automatically scale an

engineering units output from the CPU to a digital count value in the

range +/-4095. The D/A converter then converts the digital value to

an output signal voltage or current.

+20V

-1 Processor

V to I

Converter

COM

GND Case

Ground

+1

S/H

VOUT

D/A

Power

Supply

Ground

Buffer

Amplifier

Sample

Hold

Circuitry

12 bits plus

sign D/A

Converter

Common ground and case

ground terminals are shared

between output channels

NOTE:

Circuit Scaling

Each circuit can be configured for scaling to represent a different

type or increment of engineering units. The default for each circuit is

to operate in the range of +/-10VDC, and to report engineering units

of millivolts. If millivolts are not appropriate or if the circuit will

operate in a different voltage/current range, the circuit should be

rescaled. Instructions are given in the Discrete and Analog Blocks

User’s Manual. The possible range of engineering units values is

+/-32767. A circuit can also be configured for no scaling; in that

case, it uses unscaled digital count values that correspond directly

to the actual analog signal level. The range of digital counts values

is +/-4095.

LEDs _________________________________________

The block's Unit OK and I/O Enabled LEDs show its operating

status:

Unit OK I/O

Enabled

Meaning

ON ON Block functioning, CPU communicating

ON OFF Block functioning

No CPU communications for 3 bus scans

ON Blinking Block functioning, Circuit forced

Blinking ON Circuit fault, CPU communicating

Blinking OFF Circuit fault

No CPU communications for 3 bus scans

Alternate Blinking Circuit fault, Circuit forced

Synchronous

Blinking

No CPU communications - block number

conflict

OFF OFF No block power, or block faulty
