193X369ABG01   GE  Module cards in stock

193X369ABG01 GE Module cards in stock

Brand: GE                 Model number:193X369AAG01

Colour:new                  Warranty: 193X369ABG01

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.12kg

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

193X369ABG01   GE  Module cards in stock

The first four circuits on the block are inputs. They convert incoming

signal voltage or current to a digital count value in the range +/-4095.

If scaling has been configured for an input, the block automatically

scales the digital count value to an engineering units value.

Processor

Case

Ground

Shield

Filter

IN

COM

GND

JMP

A/D AMP

Analog to Digital

Converter

MUX

RTN

Power

Supply

Ground

NOTE:

Common ground and case

ground are shared between

two output channels

Circuits 5 and 6 are outputs. The block will automatically scale an

engineering units output from the CPU to a digital count value in the

range +/-4095. The D/A converter then converts the digital value to

an output signal voltage or current.

+20V

-1 Processor

V to I

Converter

COM

GND Case

Ground

+1

S/H

VOUT

D/A

Power

Supply

Ground

Buffer

Amplifier

Sample

Hold

Circuitry

12 bits plus

sign D/A

Converter

Common ground and case

ground terminals are shared

between output channels

NOTE:

Circuit Scaling

Each circuit can be configured for scaling to represent a different

type or increment of engineering units. The default for each circuit is

to operate in the range of +/-10VDC, and to report engineering units

of millivolts. If millivolts are not appropriate or if the circuit will

operate in a different voltage/current range, the circuit should be

rescaled. Instructions are given in the Discrete and Analog Blocks

User’s Manual. The possible range of engineering units values is

+/-32767. A circuit can also be configured for no scaling; in that

case, it uses unscaled digital count values that correspond directly

to the actual analog signal level. The range of digital counts values

is +/-4095.

LEDs _________________________________________

The block's Unit OK and I/O Enabled LEDs show its operating

status:

Unit OK I/O

Enabled

Meaning

ON ON Block functioning, CPU communicating

ON OFF Block functioning

No CPU communications for 3 bus scans

ON Blinking Block functioning, Circuit forced

Blinking ON Circuit fault, CPU communicating

Blinking OFF Circuit fault

No CPU communications for 3 bus scans

Alternate Blinking Circuit fault, Circuit forced

Synchronous

Blinking

No CPU communications - block number

conflict

OFF OFF No block power, or block faulty
