Brand： GE Model number：193X-451AAG03
Colour：new Warranty: 193X369ABG01
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.12kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
193X-451AAG03 GE Module cards in stock
The block’s advanced diagnostics provide the messages listed below.
Fault messages can be cleared from the Hand-held Monitor or the CPU.
High Alarm: Input over its high alarm limit
Low Alarm: Input under its low alarm limit
Open Wire: Input configured for 4-20mA is below 2mA
Overrange: Signal exceeds +32767 engineering units or +4095 counts
Underrange: Signal exceeds -32767 engineering units or -4095 counts
Configuration ___________________________________
First, the block must be configured with a Hand-held Monitor to:
Enter its Device Number (serial bus address).
Enter its Reference Number (required only for IC600 and IC550
series PLCs only).
Note: If a block is configured offline, it must be properly grounded and
have a 75 Ohm resistor installed across its Serial 1 and Serial 2
terminals. See the Discrete and Analog I/O Blocks User’s Manual for
instructions. The rest of the features can be configured either using a
Hand-held Monitor, or by sending a Write Configuration datagram to the
block from the host.
Feature Circuit
or Block
Factory
Setting
Selections
Device Number Block null 0 to 31 (a number must
be selected)
Reference
Address
Block none Depends on host CPU
type
Baud Rate Block 153.6 std 153.6 std, 153.6 ext,
76.8, 38.4 Kbd
Report Faults Circuit yes yes/no
Range Select* Circuit +/-10VDC 0-10VDC, +/-10VDC, 0-
5VDC, 5VDC, 4-20mA (1-
5VDC)
Scaling Points Circuit +/-10000,
+/-4095
+/-32767, +/-4095
Input Filter Time* Circuit 128ms none, 8-1024ms
Alarm Input Mode Circuit no yes/no
Alarm Thresholds Circuit +/-10000 +/-32767
Hold Last State Circuit no yes/no
Output Default Circuit 0 +/-32767 eng. units
BSM Present Block no yes/no
Outputs Default
Time
Block 3 bus scans 2.5/10 seconds
CPU Redundancy Block none none/standby
Configuration
Protection
Block disabled enabled, disabled
* These are setup parameters. They must NOT be changed while the
block is operating. If either is changed while the block is operating, the
voltage of the circuit also changes
