Brand： GE Model number：12NAA27AC1A
Colour：new Warranty: 193X369ABG01
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.12kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
12NAA27AC1A GE Module cards in stock
IC200MDL329 IC200MDL330 IC200MDL331
Product Name
VersaMax Discrete Output Module,
120 VAC, 0.5A per point Isolated,
8 points
VersaMax Discrete Output Module,
120 VAC 0.5A per point Isolated,
16 points
VersaMax Discrete Output Module,
120 VAC 2.0A per point Isolated,
8 points
Lifecycle Status Active Active Active
Output Voltage
85-132 VAC (47-63 Hz), 120 VAC nominal 85-132 VAC (47-63 Hz), 120 VAC nominal 85-132 VAC (47-63 Hz), 120 VAC nominal
Number of Points 8 16 8
Channel to Channel Isolation Yes Yes Yes
Load Current per Point 0.5 A per point 0.5 A per point 2.0 A per point
Input and Output Response
Time- On/Off (ms) <1/2 cycle/<1/2 cycle <1/2 cycle/<1/2 cycle <1/2 cycle/<1/2 cycle
Protection
Snubber and MOVs (each output) Snubber and MOVs (each output) Snubber and MOVs (each output)
Points per Common 8 groups of 1 Isolated points Isolated points
External Power Supply
85-132 VAC (47-63 Hz), 120 VAC nominal 85-132 VAC (47-63 Hz), 120 VAC nominal 85-132 VAC (47-63 Hz), 120 VAC nominal
Load Current
10 mA minimum per point,
0.5 A maximum per point,
5.0 A for one cycle (20 ms)
maximum inrush
10 mA minimum per point,
0.5 A maximum per point,
5.0 A for one cycle (20 ms)
maximum inrush
10 mA minimum per point,
2.0 A maximum per point,
20 A for one cycle (20 ms)
maximum inrush
5V Backplane Current
Consumption (mA)
70 maximum 140 maximum 85 maximum
LED Indicators
One LED per point shows individual
point ON/OFF status (logic side).
OK LED indicates backplane
power is present
One LED per point shows individual
point ON/OFF status (logic side).
OK LED indicates backplane
power is present
One LED per point shows individual
point ON/OFF status (logic side).
OK LED indicates backplane
power is present
Dimensions (W x H x D)
110 mm (4.3 in) x 66.8 mm (2.63 in) x
50 mm (1.956 in), not including the
height of the carrier or the
mating connectors
110 mm (4.3 in) x 66.8 mm (2.63 in) x
50 mm (1.956 in), not including the
height of the carrier or the
mating connectors
110 mm (4.3 in) x 66.8 mm (2.63 in) x
50 mm (1.956 in), not including the
height of the carrier or the
mating connectors
