Brand: GE Model number:0471L0303G001
Colour:new Warranty:DS200UDSAG1ADE
Lead Time:3-day working day Country of origin: USA
Price: Please contact us Product weight:0.12kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
0471L0303G001 GE Module cards in stock
These blocks are backward-compatible with earlier versions, and
may be used to replace them.
Any Hand-held Monitor (IC66*HHM500 or HHM501) can be used
with these blocks. However, Hand-held Monitor model
IC66*HHM501 is required to change baud rate configuration, or to
configure redundancy features. Note that older HHM model
IC66*HHM501 version 3.5 may incorrectly display the message
WIRING ERROR during normal operation. Upgrading the HHM to a
later version corrects this problem.
For an IC697 series PLC, the CPU and programming software must
be version 2.0 or later. The bus controller must be IC697BEM731C
or later.
For an IC600 series PLC, the CPU must be rev. 105 or later. For an
IC600 series “Plus” PLC rev. 110 or later is required. The
programming software must be rel. 4.02 or later.
For an IC550 series PLC, the CPU must be rev. 3.0 or later. The
programming software must be rel. 2.01 or later.
Current-source analog blocks are preferred for current-loop
applications. Please request information about:
115VAC/125VDC Current-source Analog 4 Input/2 Output Block
(IC66*BBA104)
24/48 VDC Current-source Analog 4 Input/2 Output Block (IC66*BBA024)
115VAC/125VDC Current-source Analog Output Block (IC66*BBA105)
115VAC/125VDC Current-source Analog Input Block (IC66*BBA106)
24/48 VDC Current-source Analog Block Input Block (IC66*BBA026)
Using this Datasheet ____________________________
This datasheet summarizes information about block installation,
configuration, and diagnostics.
Your primary reference should be the Discrete and Analog Blocks
User’s Manual. It includes detailed instructions for block installation
and configuration.
For additional information about systems and communications,
including bus specifications, refer to the I/O System and
Communications Manual.
Installation Instructions _________________________
Carefully inspect all shipping containers for damage. If any
equipment is damaged, notify the delivery service immediately. Save
the damaged shipping container for inspection by the delivery
service. After unpacking the equipment, record all serial numbers.
Save the shipping containers and packing material in case it is
necessary to transport or ship any part of the system.
Block Mounting
Genius I/O blocks are considered "open equipment" and therefore
must be installed within a protective enclosure. They should be
located in an area that is clean and free of airborne contaminants.
There should be adequate cooling airflow.
The block can be mounted right side up, or upside down. Leave at
least 2 inches of space between blocks. Mount the block by drilling
two screw or bolt holes for 8-32 hardware. Position the block so that
the notches in the upper and lower flanges line up with the mounting
holes. Mount the block using 8-32 screws. Use star washers to
provide ground integ
