These blocks are backward-compatible with earlier versions, and

may be used to replace them.

Any Hand-held Monitor (IC66*HHM500 or HHM501) can be used

with these blocks. However, Hand-held Monitor model

IC66*HHM501 is required to change baud rate configuration, or to

configure redundancy features. Note that older HHM model

IC66*HHM501 version 3.5 may incorrectly display the message

WIRING ERROR during normal operation. Upgrading the HHM to a

later version corrects this problem.

For an IC697 series PLC, the CPU and programming software must

be version 2.0 or later. The bus controller must be IC697BEM731C

or later.

For an IC600 series PLC, the CPU must be rev. 105 or later. For an

IC600 series “Plus” PLC rev. 110 or later is required. The

programming software must be rel. 4.02 or later.

For an IC550 series PLC, the CPU must be rev. 3.0 or later. The

programming software must be rel. 2.01 or later.

Current-source analog blocks are preferred for current-loop

applications. Please request information about:

115VAC/125VDC Current-source Analog 4 Input/2 Output Block

(IC66*BBA104)

24/48 VDC Current-source Analog 4 Input/2 Output Block (IC66*BBA024)

115VAC/125VDC Current-source Analog Output Block (IC66*BBA105)

115VAC/125VDC Current-source Analog Input Block (IC66*BBA106)

24/48 VDC Current-source Analog Block Input Block (IC66*BBA026)

Using this Datasheet ____________________________

This datasheet summarizes information about block installation,

configuration, and diagnostics.

Your primary reference should be the Discrete and Analog Blocks

User’s Manual. It includes detailed instructions for block installation

and configuration.

For additional information about systems and communications,

including bus specifications, refer to the I/O System and

Communications Manual.

Installation Instructions _________________________

Carefully inspect all shipping containers for damage. If any

equipment is damaged, notify the delivery service immediately. Save

the damaged shipping container for inspection by the delivery

service. After unpacking the equipment, record all serial numbers.

Save the shipping containers and packing material in case it is

necessary to transport or ship any part of the system.

Block Mounting

Genius I/O blocks are considered "open equipment" and therefore

must be installed within a protective enclosure. They should be

located in an area that is clean and free of airborne contaminants.

There should be adequate cooling airflow.

The block can be mounted right side up, or upside down. Leave at

least 2 inches of space between blocks. Mount the block by drilling

two screw or bolt holes for 8-32 hardware. Position the block so that

the notches in the upper and lower flanges line up with the mounting

holes. Mount the block using 8-32 screws. Use star washers to

provide ground integ
