Brand：FOXBORO Model number：FBM232
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
FBM232 FOXBORO Industrial control module spot
ETHERNET LINK SETUP
Data communication between the FBM232 and field
devices are through the RJ-45 connector located on
the front of the FBM232 module. The RJ-45
connector of the FBM232 can be connected through
hubs, or through Ethernet switches to the field
devices (refer to “ETHERNET HUBS AND
SWITCHES” on page 8). Connection of multiple
devices to the FBM232 requires a hub or switch.
CONFIGURATOR
The FDSI configurator sets up the FBM232 XML
based port and device configuration files. The port
configurator allows for easy setup of the
communication parameters for each port (such as,
Dynamic Host Configuration Protocol (DHCP), IP
addresses). The device configurator is not needed for
all devices, but when needed it configures device
specific and point specific considerations (such as,
scan rate, address of the data to be transferred, and
the amount of data to be transferred in one
transaction).
OPERATIONS
The FBM232 can access up to 64 devices to read or
write data. From the I/A Series control station to
which the FBM232 is connected, up to 2000
Distributed Control Interface (DCI) data connections
can be made to read or write data. Supported data
types are determined by the particular driver loaded
on the FBM232, which converts the data to the DCI
data types listed below:
An analog input or output value (integer or IEEE
single-precision floating point)
A single digital input or output value
Multiple (packed) digital input or output values
(packed in groups of up to 32 digital points per
connection).
Thus an I/A Series control station can access up to
2000 analog I/O values, or up to 64000 digital I/O
values, or a combination of digital and analog values
using the FBM232. The frequency of access to the
FBM232 data by a control station can be as fast as
500 ms. The performance is dependant on each
device type and the layout of data in the device.
The FBM232 collects the required data from the
devices, performs the necessary conversions
FOXBORO P0928AY
