①The title：3300/03 3300/03-01-00 Bently Servo drive industrial control module spare parts
(The picture is in the folder.)
Brand：Bently Model number：3300/03 3300/03-01-00
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：1.98kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Product Dimensions：Each Keyphasor Module accepts
up to two transducer signals from
proximity probe transducers or
magnetic pickups. The input
signal range is +0.8 V to -21.0 V
(Non-Isolated I/O modules) or +5V
to -11V (Isolated I/O modules).
Signals exceeding this range are
limited internally by the module.
Passive magnetic pickups require
a shaft rotative speed greater
than 200 rpm (3.3 Hz).
Minimum signal amplitude for
triggering is 2 volts peak to peak
and minimum frequency is 120
rpm (2 Hz).
Use for any input above 0.017 Hz
(1 rpm for 1 event/revolution).
User-selectable from 0 to -20
volts dc. Minimum signal
amplitude for triggering is 500
millivolts peak to peak.
Input range of 1 to 1,200,000 cpm
(0.017 to 20 kHz). Supports
multiple events per revolution to a
maximum of 20 kHz.
Output range of 1 to 99,999 cpm
(0.017 to 1667 Hz)
Two buffered Keyphasor outputs
are available at the front of the
rack via coaxial connectors. Two
buffered Keyphasor outputs are
also available at the back of the
rack via Euro Style connectors.
Indicates when a fault has been
detected in the Keyphasor
Module.
Indicates when the Keyphasor
Module is communicating with
the Rack Interface Module (RIM).
1 half-height front slot.
The half-height main modules
require a special mounting
adapter for mounting in the fullheight slots. The user can place
the main modules in any one of
the 14 available slots. Each rack
may have no more than two main
modules, one in a top half-slot
and one in a bottom half-slot.
Bently135489-04，Bently330130-080-00-00，Bently136703-01，Bently133396-01，Bently330730-040-00-00，Bently330130-045-00-00，Bently125720-01，Bently135473-01，Bently125840-01，Bently146031-01，Bently330850-50-05，Bently149992-01，Bently136188-02，Bently138708-01，Bently133396-01，Bently125720-01，Bently138708-01，Bently133323-01，Bently133396-01，Bently125800-01，Bently125768-01，Bently330740-000-060-10-02-00，Bently330709-000-080-10-02-00，Bently84145-01，Bently135137-01，Bently330106-05-30-10-02-00，Bently330980-51-05，Bently125720-01，Bently125800-01，Bently125768-01，Bently330103-00-06-10-02-00，Bently330730-080-00-00，
Contact person：Free
Email Address:：free@fenoux.com
WhatApp： +86 133 7698 4225
We look forward to your inquiry and will get back to you as soon as possible.
