172109-01  Bently  Servo drive industrial control module spare parts

172109-01 Bently Servo drive industrial control module spare parts

①The title:172109-01  Bently  Servo drive industrial control module spare parts

(The picture is in the folder.)

Brand:Bently            Model number172109-01

Colour:new                  Warranty: 12 months

Lead Time:3-day working day   Country of origin USA

Price: Please contact us         Product weight:1.68kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Product Dimensions:A Keyphasor signal is a once-per-turn or multiple-event-per-turn pulse from a rotating shaft or gear used to provide a precise timing measurement. This allows 3500 monitor modules and external diagnostic equipment to measure shaft rotative speed and vector parameters such as 1X vibration amplitude and phase.

The Enhanced Keyphasor Module is an improved 3500 system module. It offers expanded Keyphasor signal processing capabilities over the previous design while maintaining complete downward-compatibility in terms of form, fit and function with existing Keyphasor modules for use in legacy systems. The Keyphasor module, PWA 125792-01, is completely replaced by the more recent 149369-01 module.
When a system Keyphasor input is required for Triple Modular Redundant (TMR) applications, the 3500 system should employ two Keyphasor modules. In this configuration the modules work in parallel to provide both a primary and secondary Keyphasor signal to the other modules in the rack.
A system with more than four Keyphasor inputs may use a paired configuration provided that there are no more than four primary Keyphasor input signals. A paired configuration requires two consecutive monitoring positions in either the upper/lower or both half-slot positions. Four Keyphasor modules will accept four primary and four backup input channels and provide four output channels (one per module). A configuration of two paired and one non-paired (three Keyphasor modules total) is also possible. In such a configuration, the user may configure the one non-paired Keyphasor (order either two 2-channel or one 1-channel and one 2-channel option)
The Isolated Keyphasor I/O module is designed for applications in which the Keyphasor signals are tied in parallel to multiple devices and require isolation from other systems, such as a control system. The Isolated I/O module was created specifically for Magnetic Pickup applications but is compatible with and will provide isolation for Proximitor* applications as long as an external power supply is provided. Note that the intent of this I/O module was primarily to measure shaft speed and not phase. The module can provide phase measurements, but this I/O introduces a slightly higher phase shift than the NonIsolated I/O version. Figure 1 shows the amount of phase shift that the Isolated I/O modules will add at different machine speeds. Enhanced product features include generation of once-per-turn event signals from multi-event-per-turn inputs, field-upgradeable firmware, and asset management data reporting.


Bently135489-04,Bently330130-080-00-00,Bently136703-01,Bently133396-01,Bently330730-040-00-00,Bently330130-045-00-00,Bently125720-01,Bently135473-01,Bently125840-01,Bently146031-01,Bently330850-50-05,Bently149992-01,Bently136188-02,Bently138708-01,Bently133396-01,Bently125720-01,Bently138708-01,Bently133323-01,Bently133396-01,Bently125800-01,Bently125768-01,Bently330740-000-060-10-02-00,Bently330709-000-080-10-02-00,Bently84145-01,Bently135137-01,Bently330106-05-30-10-02-00,Bently330980-51-05,Bently125720-01,Bently125800-01,Bently125768-01,Bently330103-00-06-10-02-00,Bently330730-080-00-00,
