8 Dynamic Node Allocation (DNA)

The node numbers of all POWERLINK bus controllers can be assigned dynamically. This has the following advantages:

• No need to set the node number switch

• Easier installation

• Reduced error sources

For information about configuration as well as an example, see the AS help system (Communication → POWERLINK → General information → Dynamic Node Allocation (DNA)).

Information:

The IF1 interface must always be used as the input from the preceding node.

9 Ethernet interface

Information about cabling X20 modules with an Ethernet interface can be found in the module's download section

on the B&R website (www.br-automation.com).

IF1

IF2

Pinout Interface

Pin Ethernet

1 RXD Receive data

2 RXD\ Receive data\

3 TXD Transmit data

4 Termination

5 Termination

6 TXD\ Transmit data\

7 Termination

1

Shielded RJ45

8 Termination

10 SG3

This module is not supported on SG3 targets.

11 SG4

This module comes with preinstalled firmware. The firmware is also part of the Automation Runtime operating

system for the PLC. If the two versions are different, the Automation Runtime firmware is loaded to the module.

The latest firmware is made available automatically when updating Automation Runtime.
