Take the following points into consideration when changing the NiCd rechargeable battery if the PCC is turned

off and the APM is not inserted:

❍ The PCC must be turned on for at least 5 minutes without interruption before changing the NiCd

rechargeable battery to guarantee that the gold foil capacitor is loaded.

❍ The NiCd rechargeable battery must be changed within 10 minutes of turning off the system.

Procedure when Changing the NiCd Rechargeable Battery

1) Remove power to power supply

2) Discharge electrostatic energy by touching the mounting rail or

the ground connection (not in the power supply!)

3) Open module door

4) Pull the NiCd rechargeable battery from the battery

compartment using the removal ribbon

Attention: Do not remove or damage connection wire

5) Desolder the NiCd rechargeable battery with a

suitable tool (adjustable electronic soldering iron)

6) Resolder new NiCd rechargeable battery with proper polarity

7) Place NiCd rechargeable battery in the battery

compartment (don't forget to replace the removal strip)

8) Close module door

9) Replace voltage to power supply
