F2-04AD-1 AUTOMATION DIRECT Product Details

The F2-04AD-1 is a 4-channel analog input module for use with DirectLOGIC 205 PLCs. It is designed to accept 4-20mA current loop signals and convert them to digital values that can be used by the PLC. The module has a resolution of 12 bits (1 in 4096) unipolar (0–4096) 13 bit (1 in 8192) bipolar (-4095 – +4095).

Product Features

• 4-channel analog input

• 4-20mA current loop

• 12-bit (1 in 4096) unipolar (0–4096) 13 bit (1 in 8192) bipolar (-4095 – +4095) resolution

• On-board 250 ohm, 1/2 Watt precision resistors for over-current protection

• Analog inputs are optically isolated from the PLC logic

• Removable terminal block for easy installation and removal

• Compatible with D2-240, D2-250-1, D2-260, and D2-262 CPUs

Product Benefits

• The F2-04AD-1 is a versatile analog input module that can be used for a variety of applications.

• The module's high resolution and accuracy make it ideal for precise measurement applications.

• The on-board over-current protection and optical isolation help to protect the module from damage.

• The removable terminal block makes the module easy to install and remove.

Considerations

• The F2-04AD-1 requires a 24VDC user-supplied power supply.

• The module's analog inputs are not suitable for voltage signals.

• The module's input range is 0-20mA. Signals outside of this range will be clipped.

Product Applications

• The F2-04AD-1 can be used in a variety of applications, including:

• Process control

• Machine automation

• Data acquisition

• Test and measurement

Overall, the F2-04AD-1 is a reliable and versatile analog input module that is well-suited for a variety of industrial applications.
