HT-400-C-J   Industrial control module   card

HT-400-C-J Industrial control module card

Brand:AMCI                   Model number:HT-400-C-J

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

Colour:new                  Warranty: 12 months

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

HT-400-C-J   Industrial control module   card
NX1F4D  Industrial control module   card

1. Verify that your system’s power supply has adequate reserve current capacity. The 7662

module requires 375mA at +5Vdc.

2. The 7662 cannot be any farther than the 7th module away from the power supply.

3. Align the tongue-and-groove guides on the left side of the module with the existing rack system

and slide the module backwards.

4. When the 7662 module is in position, move the white bus connector lever on the top of the

module to the left.

5. If the 7662 module is the right most module in a system, a 1769-ECR End Cap MUST be

installed to the right of the module for the system to operate correctly.

CompactLogix Generic Configuration

1. Open RSLogix 5000 and the project in which you want to install the AMCI 7662 module.

2. Right click on I/O Configuration in the Project Tree.

3. Select New Module.

4. Select the following module type and description from the list that appears.

Type = 1769-MODULE

Description = Generic 1769 Module

5. Click on OK.

6. Enter the following module properties.

Name: Your Choice (must begin with a letter)

Description: Your Choice

Comm Format: Data-INT (The default is Input Data-INT. This must be changed to Data-INT)

Slot: location of 7662 module

7. Enter the Connection Parameters from the following table.


AMCI NX1F4D

AMCI 1242

AMCI 2762-17

AMCI 1741

AMCI 2731-04

AMCI SD17060B-25

NX1F4D

HT-400-C-J

DC25F-B1NPRGMAS

AMCI 3401

AMCI 3601

AMCI 1732H

AMCI HT-20-10

AMCI 1731

AMCI NX1F2E

AMCI SD17060E

AMCI iPLC-1-2-3

AMCI 1731-CA

AMCI 1541-03

AMCI 1541-12

1
