Brand：AMCI Model number：SD17060B
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
Colour：new Warranty: 12 months
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
AMCI SD17060B Industrial control module card
The 7662 module stores its parameters in a non-volatile flash memory when power is removed so it is
not necessary to program the module at every power up. However, this flash memory is good for a
minimum of 10,000 write cycles so the module must not be programmed during every machine cycle.
The module has two opto-coupler latching inputs that will capture the scaled sensor data on the
rising, falling, or both transitions of the input. These inputs can be wired to be sinking or
sourcing and will activate when they see a voltage level between 8 and 24Vdc across the + and
– latch terminals.
The 7662 module is shipped with channel 2 disabled. Enable channel 2 by simply programming the
channel 2 setup data. It is also possible to disable the second channel of the 7662 module. If only one
sensor is being used, disabling the second channel is recommended because the module will stop all
activities associated with channel two, thereby improving the throughput time.
Sample programs showing how to program the 7662 module in both MicroLogix and CompactLogix
systems are available from the following page of our website.
