Brand：AMCI Model number：1541-03
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
Colour：new Warranty: 12 months
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
AMCI 1541-03 Industrial control module card
8. Click on Finish >>
The 7662 module will now appear in the project tree and three new data tags will have been created,
Local:X.I.Data[Y], Local:X.O.Data[Y] and Local:X.C.Data[Y] where “X” is the slot number and “Y”
is the word number. The status, data value, velocity, latched value, and the actual SSI value are located
in the Input tags. All commands are sent to the 7662 module through the Output tags. The 7662 module
does not use the Configuration tags.
Disconnect power before attempting to install or remove the
7662 module
20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 5
Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com
7662 Manual
Two Channel MicroLogix 1500 & CompactLogix SSI Interface Module
Revision 1.4
CompactLogix RSLogix 5000 V20 or higher configuration
With the release of V20 of RSLogix 5000, the AMCI 7662 module is now present in the list of
available CompactLogix I/O modules, so you now have the option of using either this or the Generic
module described above when adding the AMCI 7662 module to your I/O.
1. Open RSLogix 5000 and the project in which you want to install the AMCI 7662 module.
2. Right click on I/O Configuration in the Project Tree.
3. Select New Module.
4. Verify that the By Vendor tab is selected at the bottom of the Select Module window and expand
Advanced Micro Controls. The following window will open.
