ABB	DS3800NMEA1H1E  Industrial control module card

ABB DS3800NMEA1H1E Industrial control module card

Brand:ABB                     Model number: DS3800NMEA1H1E

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

Colour:new                  Warranty: 12 months

hipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore
ABB DS3800NMEA1H1E  Industrial control module card

ABBDS3800HLIA  Industrial control module card

Article number 3BSE069295R1 3BSE069296R1 3BSE069297R1

Display size 7" 15.4" 15.4"

Display resolution, ratio 800 x 480 (16:9) 1280 x 800 (16:10)

Display colors TFT Color LCD with 16.7 million colors LED backlight

Brightness (cd/m2) 500 450 1000

View angle (H/V) 140/120 160/140 160/140

Dimming Maritime optimized to less than 1 cd/m2

Interaction type Resistive touch,

1 million finger touch operations

Resistive touch, 5 million finger touch operations

Processor 1.0 GHz Intel® Atom™ 1.6 GHz Intel® Atom™

Main memory 1 GB

Application memory 3,5 GB (SLC)

External storage media 1 × SD card slot (or SDHC with latest image loaded)

Realtime clock Yes

Ethernet (shielded RJ 45) 1 × 10/100 Base-T, 1 × 10/100/1000 Base-T

USB 3 × USB Host 2.0, max 500mA

Serial port 1 × RS232, 1 × RS422/485 (isolated)

Dimension W×H×D (mm) 204 × 143 × 73 410 × 286 × 83

Cut-out dimension W×H(mm) 188 × 127 394 × 270

Mounting depth mm[1] 43 (143) 76 (176)

Mounting Panel Mount and VESA 75 × 75

Net weight (kg) 1.4 4.7

Frame material, front foil Gray powder-coated aluminum, polyester Autoflex EB

Power supply 12 or 24 VDC (10-32 VDC)

Power consumption 15.8 W typical @ 24 VDC 28 W typical @ 24 VDC

Protection (front/rear) IP66, NEMA 4X / IP20

Operating temperature -30 to +70 °C

Relative operating humidity 5-85% non-condensing

Storage temperature -40 to +85 °C

Vibration/shock 4 G / 40 G

Environmental and Certification (1) CE: EN61000-6-4, EN61000-6-2

UL/cUL 61010-2-201 (replacement for UL 508), UL50E Type 4X outdoor

DNV, GL, ABS, LR, KR DNV, GL, ABS, LR

Hazardous Location: Ul/cUL 12.12.01 (UL1604 replacement) Class I Div 2, ATEX (Zone 2), IECEx Ex nA IIC Gc, IEC 60079-0

and IEC 60079-15

RoHS compliance: EN 50581:2012

WEEE compliance: DIRECTIVE/2012/19/EU

(1) For detailed information on each module, please visit:

 www.800xahardwareselector.com
