Brand：ABB Model number： DS3800NCBA1A1B
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
Colour：new Warranty: 12 months
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
ABB DS3800NCBA1A1B Industrial control module card
Article number 3BSE069295R1 3BSE069296R1 3BSE069297R1
Display size 7" 15.4" 15.4"
Display resolution, ratio 800 x 480 (16:9) 1280 x 800 (16:10)
Display colors TFT Color LCD with 16.7 million colors LED backlight
Brightness (cd/m2) 500 450 1000
View angle (H/V) 140/120 160/140 160/140
Dimming Maritime optimized to less than 1 cd/m2
Interaction type Resistive touch,
1 million finger touch operations
Resistive touch, 5 million finger touch operations
Processor 1.0 GHz Intel® Atom™ 1.6 GHz Intel® Atom™
Main memory 1 GB
Application memory 3,5 GB (SLC)
External storage media 1 × SD card slot (or SDHC with latest image loaded)
Realtime clock Yes
Ethernet (shielded RJ 45) 1 × 10/100 Base-T, 1 × 10/100/1000 Base-T
USB 3 × USB Host 2.0, max 500mA
Serial port 1 × RS232, 1 × RS422/485 (isolated)
Dimension W×H×D (mm) 204 × 143 × 73 410 × 286 × 83
Cut-out dimension W×H(mm) 188 × 127 394 × 270
Mounting depth mm[1] 43 (143) 76 (176)
Mounting Panel Mount and VESA 75 × 75
Net weight (kg) 1.4 4.7
Frame material, front foil Gray powder-coated aluminum, polyester Autoflex EB
Power supply 12 or 24 VDC (10-32 VDC)
Power consumption 15.8 W typical @ 24 VDC 28 W typical @ 24 VDC
Protection (front/rear) IP66, NEMA 4X / IP20
Operating temperature -30 to +70 °C
Relative operating humidity 5-85% non-condensing
Storage temperature -40 to +85 °C
Vibration/shock 4 G / 40 G
Environmental and Certification (1) CE: EN61000-6-4, EN61000-6-2
UL/cUL 61010-2-201 (replacement for UL 508), UL50E Type 4X outdoor
DNV, GL, ABS, LR, KR DNV, GL, ABS, LR
Hazardous Location: Ul/cUL 12.12.01 (UL1604 replacement) Class I Div 2, ATEX (Zone 2), IECEx Ex nA IIC Gc, IEC 60079-0
and IEC 60079-15
RoHS compliance: EN 50581:2012
WEEE compliance: DIRECTIVE/2012/19/EU
(1) For detailed information on each module, please visit:
www.800xahardwareselector.com
