Brand：ABB Model number：DS3800DEPB1A1A
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
Colour：new Warranty: 12 months
hipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
ABB DS3800DEPB1A1A Industrial Control Module Spare Parts
Application Information
Circuit Voltage
The Bulletin 1489-M circuit breakers are rated by voltage
class. Applications should not exceed the listed voltage and
current range.
Circuit Frequency
The Bulletin 1489-M circuit breakers may be applied to
frequencies of 50 Hz and 60 Hz without derating. For
applications above 60 Hz, contact Rockwell Automation with
specific application information for the derating of the circuit
breakers.
Available Short Circuit Current
The Bulletin 1489-M circuit breakers should only be applied
in those applications in which the available short-circuit (or
fault) current is less than or equal to 10 kA (US/Canada) and
15 kA (IEC).
Application Considerations
Tripping Characteristics
The trip curve characteristics are shown on the following
pages. The trip bands shown for each breaker represent
current tripping limits for a circuit breaker and are within the
limits established by UL.
The standard tripping characteristic for Bulletin 1489-M is
Type C. Type C has a magnetic trip activated at 5-10 times
the rated current of the circuit breaker. The reference
temperature for the thermal tripping characteristics is 30 °C.
The Type C characteristic will suit most applications.
In rare occurrences when the Type C characteristic does not
fully meet the application, Type D magnetic trip
characteristic is available, allowing for transients
approximately twice as high as the standard Type C.
