ABB TU830V1 3BSE013234R1: A Comprehensive Overview

Product Description

The ABB TU830V1, bearing the part number 3BSE013234R1, is an Extended Module Termination Unit designed for use with ABB Advant S800 I/O and ABB Advant-800xA systems.

This unit is specifically engineered to provide a reliable and efficient connection for various industrial automation applications.

Key Features and Benefits

• Versatility: The TU830V1 is equipped with 2x16 signal terminals, offering a flexible solution for connecting a wide range of devices and sensors.



  Reliability: Constructed with high-quality materials, this termination unit is designed to withstand harsh industrial environments and provide long-term, dependable performance.

• Ease of Use: The TU830V1 is straightforward to install and integrate into existing automation systems, reducing downtime and increasing productivity.

• Compatibility: This unit is specifically designed to work seamlessly with ABB Advant S800 I/O and ABB Advant-800xA systems, ensuring compatibility and interoperability.

• Rated Isolation: The TU830V1 offers a rated isolation of 50V, providing protection against electrical interference and ensuring the safety of connected devices.



  Technical Specifications

• Part Number: 3BSE013234R1

• ABB Type Designation: TU830V1

• Description: Extended Module Termination Unit, 2x16 signal terminals

• Rated Isolation: 50V

• Dimensions: 5.0" x 3.0" x 5.0" (12.7 cm x 7.6 cm x 12.7 cm)

• Weight: 0 lbs 12.0 oz (0.3kg)

Applications

The ABB TU830V1 finds applications in a variety of industries, including:

• Process automation: Connecting sensors, actuators, and other field devices in industrial processes.

• Machine control: Providing reliable signal termination for machine control systems.

• Building automation: Integrating with building automation systems for monitoring and control.

Static Sequence Control Board and General Drive Controller Module

While the TU830V1 itself is a termination unit, it is often used in conjunction with static sequence control boards and general drive controller modules. These components work together to create a comprehensive automation solution.

• Static Sequence Control Board: A static sequence control board is a programmable logic controller (PLC) that uses hardwired logic to control a specific sequence of operations.

• General Drive Controller Module: A general drive controller module is used to control the speed and torque of electric motors in various industrial applications.

In summary, the ABB TU830V1 is a versatile and reliable termination unit that plays a crucial role in industrial automation systems. Its compatibility with ABB Advant S800 I/O and ABB Advant-800xA systems, along with its robust construction, make it an excellent choice for a wide range of applications.

Would you like to know more about specific aspects of this product, such as its installation, configuration, or compatibility with other devices?

Please feel free to ask any further questions.
