Brand：Allen-Bradley Model number： 1756-TBNH
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.22kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Allen-Bradley 1756-TBNH Industrial control module machine spare parts
The 1769-IR6 module receives and stores digitally converted analog data from RTDs
or other resistance inputs, such as potentiometers. The module supports
connections from any combination of up to 6 RTDs or other resistance inputs. See
the input specifications on page 20 for supported RTD and resistance types, their
associated temperature ranges, and the analog input signal ranges that each
channel supports. Each of the 6 input channels is individually configurable for a
specific input device and provides open- or short-circuit and over- or under-range
indication.
The module can be attached to the controller or an adjacent I/O module before or
after mounting. For mounting instructions, see “Panel Mounting” on page 6, or
“DIN Rail Mounting” on page 7. To work with a system that is already mounted, see
“Replacing a Single Module within a System” on page 7.
The following procedure shows you how to assemble the Compact I/O system.
1. Disconnect power.
2. Check that the bus lever of the module to be installed is in the unlocked
(fully right) position.
3. Use the upper and lower tongue-and-groove slots (1) to secure the modules
together (or to a controller).
4. Move the module back along the tongue-and-groove slots until the bus
connectors (2) line up with each other.
5. Push the bus lever back slightly to clear the positioning tab (3). Use your
fingers or a small screwdriver.
Known Anomalies
No known anomalies have been identified with this revision.
