Brand： Allen-Bradley
Model number：2094-BM03-S
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA
Price: Please contact us
Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servzce: Professional Sales provides 24 hours /7 days online service
2094-BM03-S Allen-Bradley Output Module
The leftmost slot on each power rail is the converter slot, which is used by only the IAM module. All other slots are inverter
slots and are used by the AM, IPIM, or shunt module (refer to the figure below). The power rail catalog number indicates
the number of available inverter slots.
For example, the 2094-PRS1 power rail contains one inverter slot. This limits the use of this power rail to systems requiring
only one inverter slot. Similarly, the 2094-PRS8 power rail contains eight inverter slots. This limits the use of this power
rail to systems requiring up to eight inverter slots.
When selecting a power rail, determine the number of inverter slots required by all rail-mounted modules and select a
power rail with that minimum number of inverter slots.
Power Rail Slots
IMPORTANT If you select a power rail with slots exceeding the minimum required for your system, you must install a 2094-PRF slot-filler
module in each unused slot.
.
.
