Brand： Allen-Bradley
Model number: 2090-XNSM-M
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA
Price: Please contact us
Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servzce: Professional Sales provides 24 hours /7 days online service
2090-XNSM-M Allen-Bradley Processor modules, programmable controllers
Allen-Bradley 1769-L24ER-QB1B Controller: Detailed Description
The Allen-Bradley 1769-L24ER-QB1B is a CompactLogix 5370 L2 controller. It's a key component in Rockwell Automation's CompactLogix family, providing control capabilities for small to medium-sized applications.
Product Parameters/Specifications:
Processor: CompactLogix 5370 L2
Memory: 0.75 MB (750 KB) user memory
Ethernet Ports: Two Ethernet/IP ports with Device Level Ring (DLR) capability for network redundancy.
USB Port: One USB port for programming and online access.
Serial Port: One RS-232 serial port for communication with devices that don't support Ethernet/IP.
Embedded I/O: 16 digital inputs (24V DC) and 16 digital outputs (24V DC).
I/O Expansion: Supports up to four 1769 I/O modules for expanding the number of I/O points.
Communication Protocols: Ethernet/IP, DF1, DH-485, ASCII.
Number of Tasks: Supports up to 32 tasks.
Programs per Task: Supports up to 100 programs per task.
Programming Languages: Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), Sequential Function Chart (SFC).
Mounting: DIN rail mounting.
Power Supply: 24V DC input with embedded power supply for the controller and embedded I/O.
SD Card: Shipped with a 1 GB SD card (supports up to 2 GB).
Operating Temperature: 0 to 60 °C (32 to 140 °F).
Product Advantages:
Compact Size: Suitable for applications with limited panel space.
Integrated Ethernet/IP: Provides high-speed communication and connectivity to other devices on the network.
DLR Support: Offers network redundancy for improved system reliability.
Embedded I/O: Reduces hardware costs and simplifies wiring for smaller applications.
Scalability: Supports I/O expansion for larger applications.
Powerful Processor: Provides sufficient processing power for complex control tasks.
Multiple Programming Languages: Offers flexibility for different programming styles.
SD Card Support: Allows for program storage, data logging, and firmware updates.
Static Sequence Control and General-Purpose Drive Controller Modules (in the context of the 1769-L24ER-QB1B):
The 1769-L24ER-QB1B is a controller that implements static sequence control and interfaces with drive controller modules.
.
