1769-OW8I Allen-Bradley Compact I/O Accessories
Brand：Allen-Bradley Model number：1769-OW8I
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：0.195kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
1769-OW8I Allen-Bradley CompactLogix Relay Output Module
• Once the modules are locked together, the system becomes a rugged assembly.
• Upper and lower tongue-and-groove slots guide the module during installation and secure the module within the
system.
• Removable terminal blocks help ease the wiring task.
• Self-lifting, field-wire pressure plates cut installation time.
• The patented bus connector with the lock function enables consistent and system communication.
• A color bar is provided on the front of the module.
• Digital and field circuits are optically isolated.
Technical Specifications - 1769-OW8
Attribute 1769-OW8
Outputs 8 normally open (4 points/group)
Operating voltage range 5…265V AC
5…125V DC
Delay, on 10 ms
Delay, off 10 ms
Current draw @ 5.1V 125 mA
Current draw @ 24V 100 mA
Heat dissipation, max 2.83 W
Off-state leakage, max 0 mA
On-state current, min 10 mA @ 5V DC
Current per point, max 2.5 A
Current per module, max 16 A
Isolation voltage
Verified by one of these dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s, output point to bus and
group to group
265V AC working voltage (IEC Class II reinforced insulation)
Weight, approx 280 g (0.61 lb)
Dimensions (HxWxD), approx 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Height with mounting tabs 138 mm (5.43 in.)
Slot width 1
Module location DIN rail or panel mount
Power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating 8 modules
Terminal screw torque 0.68 Nlm (6 lblin)
Retaining screw torque 0.46 Nlm (4.1 lblin)
Wire size (22…14 AWG) solid
(22…16 AWG) stranded
Wire type Cu-90 °C (194 °F)
Replacement terminal block 1769-RTBN10 (1 per kit)
