Brand：Allen-Bradley Model number: 1769-OV16
Colour：new Warranty: 12 months
Lead Time：3-day working day Country of origin: USA
Price: Please contact us Product weight：1.7kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
1769-OV16 Allen-Bradley Output Module
Protection Circuit Breakers may provide the following protective and control functions.
• Disconnect for Motor Branch Circuit
• Branch-Circuit, Short-Circuit Protection (Magnetic Protection)
• Overload Protection (Thermal Protection)
• Switching (Manual)
In North America, electrical codes require that an individual Motor Branch Circuit be protected by a UL/CSA Listed Fuse, Circuit Breaker or SelfProtected Combination Motor Controller.
140M-C, D, and F Frames
The 140M-C, D, and F frame Motor Protection Circuit Breakers may have two cULus Listings - as Manual, Self-Protected Combination Motor
Controllers and as Manual Motor Controllers (with optional approvals for Motor Disconnect and Group Installation). Cat. No. 140M-D8V* can
also be applied at the output of a variable frequency drive (VFD) in multi-motor applications. See Application Conditions (140M-D8V) on
page 41 for more information.
When UL/CSA listed as Manual, Self-Protected Combination Motor Controllers, the 140M Motor Protection Circuit Breakers provide all of the
necessary NEC/CEC requirements for the protection and control of individual Motor Branch Circuits without additional protective devices.
At some higher voltages and currents (particularly at 600V), a few of the 140M-C, D, and F frame devices are only UL/CSA Listed as Manual
Motor Controllers (with optional approvals for Motor Disconnect and Group Installation). In NEC/CEC Group Installations, these devices must
be applied per the appropriate rules which require the use of an upstream Branch-Circuit, Short-Circuit Protective Device (BCPD).
1768-ENBT module
1734-OB8S
1734-4IOL
1734-IE2V
1734-IB8S
1747-L553
1756-L72
1756-OF8
1769-IF4
1769-L18ERM-BB1B
