1769-IR6 Allen-Bradley RTD/Resistance Input Module RTD

BENEFITS:(I WILL GIVE YOU A REPLY IMMEDIATELY)

Quantity available: 1

The colour:100% New Original Genuine Products

Warranty: 12 months.

Lead time: 3 days.

Payment: T/T 、 Western Union.

Transport: In Stock Ready for Shipment via DHL, TNT, FEDEX, UPS, ARAMEX and etc

Service:Professional Sales Provide 24hours/7 day Online Services

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!  We Can transport to the world!!!









1769-IR6 Allen-Bradley RTD/Resistance Input Module RTD

1769-IR6 Allen-Bradley RTD/Resistance Input Module RTD

Brand:Allen-Bradley      Model number:1769-IR6

Colour:new                  Warranty: 12 months

Lead Time:3-day working day   Country of origin: USA

Price: Please contact us         Product weight:0.22kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service


The 1769-IR6 module receives and stores digitally converted analog data from RTDs

or other resistance inputs, such as potentiometers. The module supports

connections from any combination of up to 6 RTDs or other resistance inputs. See

the input specifications on page 20 for supported RTD and resistance types, their

associated temperature ranges, and the analog input signal ranges that each

channel supports. Each of the 6 input channels is individually configurable for a

specific input device and provides open- or short-circuit and over- or under-range

indication.

The module can be attached to the controller or an adjacent I/O module before or

after mounting. For mounting instructions, see “Panel Mounting” on page 6, or

“DIN Rail Mounting” on page 7. To work with a system that is already mounted, see

“Replacing a Single Module within a System” on page 7.

The following procedure shows you how to assemble the Compact I/O system.

1. Disconnect power.

2. Check that the bus lever of the module to be installed is in the unlocked

(fully right) position.

3. Use the upper and lower tongue-and-groove slots (1) to secure the modules

together (or to a controller).

4. Move the module back along the tongue-and-groove slots until the bus

connectors (2) line up with each other.

5. Push the bus lever back slightly to clear the positioning tab (3). Use your

fingers or a small screwdriver.


Known Anomalies

No known anomalies have been identified with this revision.
