Brand： Allen-Bradley
Model number：1766-L32AWAA
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA
Price: Please contact us
Product weight：0.22kg
hipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Servzce: Professional Sales provides 24 hours /7 days online service
1766-L32AWAA Allen-Bradley Safety Laser Sensor Scanner
Mounting Kits
Mounting kits are available to mount the SafeZone safety laser scanner.
There are four possible ways to mount the SafeZone safety laser scanner:Direct mount without mounting kit
Mount with kit 1
Mount with kits 1 and 2
Mount with kits 1, 2, and 3
The mounting kits build upon each other. To mount with kit 2, you also need kit 1To mount with mounting kit 3, you also need mounting kits 1 and 2. Part numbersfor the mounting kits are listed in Fiqure 3.
IMPORTANT
Observe the maximum torque of the fastening hardware forthe SafeZone laser scanner:M6 on rear = 12 Nm(106.2 lb-in) maxM8 on side = 16 N-m (141.6 lb-in) max
Use mounting kit 1 to mount the SafeZone safety laser scanner to a surface in theback of the scanner.
Use mounting kit 2 (only with mounting kit 1) to align the scanner in two planes. Themaximum adjustment angle is 7 in both planes.
Use mounting kit 3 (only with mounting kits 1and 2) to mount the SafeZone scannerso that the scan plane is parallel to the mounting surface and is also used floormounting.
Figure 3 - Mounting Kits
Mounting Kit 3
442L-AMBSFZNMZ3
Mounting Kit 2442L-AMBSFZNMZ2
Mounting Kit 1442L-AMBSFZNMZ1
Sensor Mounting
Screws
Threaded Mounting Holes
M8 x9
During mounting, observe the dimensional drawings inpublication 442L-UM003
