1756-L73 Allen-Bradley

1756-L73   Allen-Bradley Module spare parts spot

Install a System

Based on your application design, you must install a Compact GuardLogix 5380

controller, or a Compact 5000 I/O EtherNet/IP™ adapter before you can install the

module.

For more information on how to install these components, see Additional Resources on

page 11.

Module Orientation

You can install the 5069-OBV8S and 5069-OBV8SK modules in these system

orientations:

• Horizontal

• Inverted Horizontal

• Vertical

• Inverted Vertical

• Upside Down

• Upside Up

Required Components

To install the module, you need the following components.

Module Status and

SA Indicators

I/O Status Indicator

Top Interlocking Piece

Bottom Interlocking Piece

DIN Rail Latch

RTB Handle

RTB

MOD Power Bus and SA

Power Bus Connectors

(isolated from each

other internally)

RTB Lower Tab

Lower hook for use

with cable tie.

IMPORTANT Remember the following:

• The controller or adapter dictates the system orientation.

For example, the module supports Upside Down orientation.

You cannot use the module in the Upside Down orientation

unless the controller or adapter supports it.

For more information on the orientations that Compact

GuardLogix 5380 controllers or Compact 5000 EtherNet/IP

Adapters support, see Additional Resources on page 11.

• The module is de-rated when the system is mounted in any

orientation other than Horizontal.

For more information, see Specifications on page 10.

Component Description

Removable terminal

blocks

One of the following RTB types.

• 5069-RTB18-SPRING RTB

• 5069-RTB18-SCREW RTB

IMPORTANT: You must order RTBs separately. RTBs do not ship with

Compact 5000 I/O modules. We recommend that you order only the

RTB type that your system requires.

End cap An end cap ships with the Compact GuardLogix 5380 controllers a
