1756-IF16 Allen-Bradley

Before you install your module, you should:

install and ground a 1756 chassis and power supply.

order and receive an RTB or IFM, and its

components, for your application.

Identify the Module Components

You received the following components with your order:



1756-IF16 module



Removable Terminal Block (RTB) door label

If you did not receive these components, contact your local

distributor Rockwell Automation sales office.

This module mounts in a 1756 chassis and uses a separately-ordered

RTB or a Bulletin 1492 Interface Module (IFM)(1) to connect all

field-side wiring. This module uses one of the following RTBs:



1756-TBCH 36 position Cage clamp RTB



1756-TBS6H 36 position Spring clamp RTB

Use an extended-depth cover (1756-TBE) for applications with heavy

gauge wiring or requiring additional routing space. When using an

IFM, consult the documentation that came with it to connect wiring.

Note the Power Requirements

This module receives power from the 1756 chasis power supply and

requires 2 sources of power from the backplane:



150mA at 5.1V dc



65mA at 24V dc

Add this current/power value (2.33W) to the requirements of all other

modules in the chassis to prevent overloading the power supply.

(1) The Bulletin 1492 IFM may not be used in any application that requires agency certification of the

ControlLogix system. Use of the IFM violates the UL, CSA and FM certifications of this product.
