150-F85NBR Allen-Bradley.

150-F85NBR    Allen-Bradley.    AC Servo driver

IMPORTANT If you use wires without lugs, make sure the wires are securely captured

by the pressure plate. This is particularly important at the four end

terminal positions where the pressure plate does not touch the outside

wall of the controller.

IMPORTANT Be careful when stripping wires. Wire fragments that fall into the

controller could cause damage. Remove the protective wrap after wiring

your controller. Failure to remove the wrap may cause the controller to

overheat.

IMPORTANT This symbol denotes a functional earth ground terminal which

provides a low impedance path between electrical circuits and

earth for non-safety purposes, such as noise immunity improvement.

Protective

Wrap

MicroLogix 1000 Programmable Controllers 15

Publication 1761-IN001D-EN-P - June 2015

Grounding Your Controller

In solid-state control systems, grounding helps limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the ground screw of

the controller (third screw from left on output terminal rung) to the ground bus. Use the

heaviest wire gauge listed for wiring your controller.

.
