2. Observe these guidelines for use of the DIP switches:

• Out of the box, all three switches are in the Off position. In this state,

the 1783-NATR device is configured to be a non-supervisor ring node

and responds to the default IP address of 169.254.1.1 for the Public

port and DHCP for the Private ports.

• The 169.254.1.1 address is used only during the initial configuration.

When configuring 1783-NATR for translations, change the Public port

IP address to the assigned address in the plant-wide network. Choose

alternate DIP switch settings or configure the 1783-NATR device by

using RSLinx Classic communication software, Studio 5000 Logix

Designer programming software, or the Device Manager Webinterface.

• When a switch is pushed to the left when viewing the front of the

device, it is in the Off position.

• When a switch is pushed to the right when viewing the front of the

device, it is in the On position.

• To configure the ports with a static address, move switch 1 to the Off

position and switch 2 to the On position.

• To enable Ring Supervisor mode with the current supervisor-related

parameters, move switch 3 to the On position.

• To restore the factory default settings and suspend operation, move

switch 1 and 2 to the On position. When switch 1 and 2 are in the On

position, the position of switch 3 is ignored.

When operation is suspended, the OK status indicator blinks red. To resume

normal operation, move the switches to the desired positions and cycle power to

the 1783-NATR device.
