100-K1210 A-B

Coil Voltage Code: The Cat. No. as listed is incomplete. Select a coil voltage code from the table below to complete the Cat. No. Example:

120V, 60 Hz: Cat. No. 100-FL11Ä becomes Cat. No.100-FL11D

Pneumatic Timing Modules

• Pneumatic timing element contacts switch after the delay

time. The contacts on the main control relay continue to

operate without delay

On-Delay

0.3…30 s 100-C or 700-CF with

AC or 24V DC

electronic coils(1)

(1) Cannot be used with side-mounted auxiliary contacts on 700-CF DC relays.

100-FPTA30

2...180 s 100-FPTA180

Off-Delay

0.3...30 s

100-C all, 700-CF all

100-FPTB30

2...180 s 100-FPTB180

Electronic Timing Modules — On-delay

• Delay of the contactor or control relay solenoid. The contactor or

control relay is energized at the end of the delay time.

0.1...3 s

100-C or 700-CF with

110...240V, 50/60Hz

coils

100-ETA3

1...30 s 100-ETA30

10...180 s 100-ETA180

0.1...3 s

100-C or 700-CF with

24VDC coils

100-ETAZJ3

1...30 s 100-ETAZJ30

10...180 s 100-ETAZJ180

Electronic Timing Modules — Off-delay

• Delay of the contactor or control relay solenoid. After interruption of

the control signal, the contactor or control relay is de-energized at

the end of the delay time.

0.3...3 s

100-C09...C37 or 700-

CF with 24V 50/60Hz

100-ETBKJ3

1...30 s 100-ETBKJ30

10...180 s 100-ETBKJ180

0.3...3 s 100-C or 700-CF with

110...240V 50/60Hz

coils

100-ETB3

1...30 s 100-ETB30

10...180 s 100-ETB180

Electronic Timing Modules

• Delay of the contactor solenoid. Contactor K 3(Y) is deenergized (off) and K 2 (D) is energized (on) after the end

of the set Y end time. (Switching delay at 50 ms.)

• Continuous adjustment range

• High repeat

Transition Time Y

Contactor 1...30 s

100-C with 110...240V

50/60Hz coils 100-ETY30

Mechanical Interlocks

• For interlocking of two contactors.

• Common interlock for most Bul. 100-C contactor sizes

• Interlocking of different sizes possible

• Mechanical and electrical interlocking possible in one

module by means of integrated auxiliary contacts

• 9 mm dovetail connector included

Mechanical only, without

auxiliary contacts

100-C (except 100-

C40, -C90) 100-MCA00

Mechanical/ electrical

interlock with 2 N.C.

auxiliary contacts

100-C (except 100-

C40, -C90) 100-MCA02

Mechanical Latch

• Following contactor latching, the contactor coil is

immediately de-energized (off) by the N.C. auxiliary

contact (65-66).

• Electrical or manual release

• 1 N.O. + 1 N.C. auxiliary contacts

• Suitable for all Bul. 100-C contactor sizes, 9...97 A

Maximum command

duration 0.03...10 s

100-C with AC or 24V

DC electronic coils

(except 100-C90)

100-FL11Ä
